Digital Flow meter

Name: Digital Flow meter
Brand: MARS PRODUCTS & SERVICES
Price: 250000 INR
Availability: InStock

Price 250000 INR/ Meter

Get a Price/Quote

MOQ : 1 Meter

Digital Flow meter Specification

Sensor Type
Electromagnetic/Turbine/Ultrasonic

Temperature Range
-20C to +80C

Protection
IP65, IP67

Pressure Range
0-16 Bar

Signal Type
Analog or Digital

Mounting
Inline Flange/Threaded

Application Media
Water, Oil, Gas, Chemicals

Axis Type
Single Axis

Model
Customizable as per requirement

Sensitivity
0.01 m3/h

Operating Temperature
-20C to +80C

Measurement Range
0.5 to 10,000 m3/h

Process Connection
DIN/ANSI Flange, BSP/NPT Thread

Stability
0.1% FS/year

Color
Blue/Black/Silver

Connector
Cable gland/Terminal block

Storage Temperature
-40C to +85C

Current Range
4-20mA

Frequency
50/60Hz

Output
4-20mA, Pulse, RS485, Modbus

Flow Rate
0.5 to 10,000 m3/h

Diameter
DN 15 to DN 300 mm

Housing Material
SS/Aluminum Die-cast

Capacity
Up to 10,000 m3/h

Input
24V DC/230V AC

Velocity Range
0.1 to 15 m/s

Response Time
<1s

Measuring Units
litres/hr, m3/hr, gallons

Humidity %
95% RH, Non-Condensing

Connectivity Type
Wired (optional wireless)

Resolution
0.001 m3/h

Load Capacity
Up to 16 Bar

Dimension (L*W*H)
Varies by model

Connecting Type
Flange, Thread

Language
English

Length
Depends on diameter

Material
Stainless Steel/Carbon Steel/Aluminum

Power Supply
24V DC or 230V AC

Power Consumption
<20W

Accuracy
1% of reading

Display Type
Digital LCD/LED

Range
0.5 to 10,000 m3/h

Replacement Interval
5 Years (recommended)

Ambient Temperature Range
-10C to +60C

Communication Interface
RS485 MODBUS RTU

Display Features
Backlit, programmable

Alarm Output
Relay (configurable)

Power Supply Variation Tolerance
10%

Calibration
Factory calibrated with certificate

Transducer Material
Stainless Steel 316

Enclosure
Weatherproof, dustproof

Zero Drift
<0.1% FS/year

Installation Type
Horizontal/Vertical

Maintenance
Low, No moving parts

Equipment Type
Digital Flow Meter

Surge Protection
In-built

About Digital Flow meter

A digital diesel flow meter is an electronic device used to measure the flow and total consumption of diesel fuel with high accuracy (+/-0.5%). It typically uses an oval gear or turbine sensor, has an LCD display for instant and total readings, and provides pulse or 4-20 mA outputs for monitoring systems. The meter operates on battery or 24 VDC power, with a robust aluminum or stainless-steel body suitable for industrial and fuel transfer applications.

Advanced Flow Measurement Technology

Utilizing electromagnetic, turbine, or ultrasonic sensors, the Digital Flow Meter ensures precise measurement with 1% reading accuracy, even in demanding environments. Its durable construction in Stainless Steel 316 and weatherproof enclosures guarantee long-term performance across varied applications, from water treatment plants to chemical processing lines.

Flexible Installation and Seamless Integration

Designed for both horizontal and vertical installation, this flow meter accommodates diverse pipeline layouts. It supports multiple measuring units-litres/hr, m3/hr, and gallons-and features programmable relay alarms, RS485 MODBUS RTU interface, and optional analog outputs, ensuring compatibility with existing control systems and ease of configuration.

Low Maintenance and Operational Reliability

With no moving parts, an in-built surge protector, and robust construction, the Digital Flow Meter offers low maintenance and reliable operation. Certified calibration, minimal zero drift (<0.1% FS/year), and long replacement intervals (up to 5 years) ensure user peace of mind, even in harsh and fluctuating environments.

FAQ's of Digital Flow meter:

Q: How is the Digital Flow Meter installed and configured for different pipe layouts?

A: The meter is suitable for both horizontal and vertical installations, with inline flange or threaded process connections (DIN/ANSI, BSP/NPT). It can be adapted to various pipe diameters (DN 15 to DN 300 mm), and configuration is user-friendly through the backlit, programmable display and digital interface.

Q: What are the main benefits of using a Stainless Steel 316 transducer in this flow meter?

A: Stainless Steel 316 offers superior corrosion resistance, ensuring durability and compatibility with various media such as water, oils, gases, and chemicals, making the flow meter ideal for harsh industrial environments and long-term deployment.

Q: When should the Digital Flow Meter be replaced or recalibrated?

A: The device is factory-calibrated and delivered with a certificate. It is recommended to consider replacement or factory recalibration every 5 years to maintain optimal accuracy and performance.

Q: Where can the Digital Flow Meter be used effectively?

A: It is engineered for a broad range of industrial applications, including chemical processing, oil and gas, water treatment, and more, thanks to its robust material options, wide flow and pressure range (up to 10,000 m3/h; up to 16 bar), and weatherproof/dustproof IP65/IP67 rated enclosure.

Q: What is the process for integrating the flow meter with plant automation systems?

A: The meter supports RS485 MODBUS RTU protocol for digital connectivity, along with 4-20 mA and pulse outputs, allowing straightforward integration with SCADA, PLCs, or remote monitoring systems using wired (or optional wireless) connections.

Q: How is maintenance simplified, and what makes it low-maintenance?

A: With no moving parts, robust electronic design, and a weatherproof, dustproof housing, routine maintenance is minimized. The built-in surge protection and stable zero drift ensure long intervals between servicing.
